Multichannel negative filters block groups (or tiers) of channels from nonpaying subscribers. The trap filters out selected frequencies, utilizing a passband that allows (or passes) the frequencies (channels) purchased by the subscriber and a reject band that blocks the frequencies from subscribers who did not pay for them.
Specifications:
Connection Type: “F” (Male/Female)
Rejection: -50 dB, typ. -45 dB min
Insertion Loss: -2 dB typ.
Band Edges: -3 dB to -5 dB
Passbands: Up to 2GHz (Style/Design Dependent)
Impedance: 75 Ohms
Condition: New
Product Overview:
Multichannel negative filters block groups (or tiers) of channels from nonpaying subscribers. The trap filters out selected frequencies, utilizing a passband that allows (or passes) the frequencies (channels) purchased by the subscriber and a reject band that blocks the frequencies from subscribers who did not pay for them.
Specifications:
Connection Type: “F” (Male/Female)
Rejection: -50 dB, typ. -45 dB min
Insertion Loss: -2 dB typ.
Band Edges: -3 dB to -5 dB
Passbands: Up to 2GHz (Style/Design Dependent)
Impedance: 75 Ohms
