Description: The diagnostic-supported XFP transceiver offers comprehensive monitoring capabilities, including laser bias current, RX input power, case temperature, and power supply voltage, ensuring efficient and reliable performance. With a signaling rate of 40 Gbps per lane and 12 transmitter fibers, this transceiver is well-suited for high-speed data transfer. The transmitter operates at a wavelength range of 850 nm, with a minimum output power of -7.6 dBm and a maximum of 2.4 dBm per lane. The receiver, spanning a range from -9.5 dBm to 2.4 dBm per lane, guarantees effective data reception. Designed for compatibility with multimode fibers (MMF) of core size/cladding 50/125 µm, it supports both OM3 and OM4 fiber grades. The transceiver ensures a reliable link over distances of 100 m to 150 m, with a maximum power consumption of 3.5 W. Operating within a temperature range of 0°C to 70°C and suitable for storage between -40°C to 85°C, this XFP transceiver offers a robust solution for a variety of networking environments.
Features:
Comprehensive Monitoring
High-Speed Data Transfer
Wavelength Range
Versatile Fiber Compatibility
Reliable Link and Distance
Condition: New
Description: The diagnostic-supported XFP transceiver offers comprehensive monitoring capabilities, including laser bias current, RX input power, case temperature, and power supply voltage, ensuring efficient and reliable performance. With a signaling rate of 40 Gbps per lane and 12 transmitter fibers, this transceiver is well-suited for high-speed data transfer. The transmitter operates at a wavelength range of 850 nm, with a minimum output power of -7.6 dBm and a maximum of 2.4 dBm per lane. The receiver, spanning a range from -9.5 dBm to 2.4 dBm per lane, guarantees effective data reception. Designed for compatibility with multimode fibers (MMF) of core size/cladding 50/125 µm, it supports both OM3 and OM4 fiber grades. The transceiver ensures a reliable link over distances of 100 m to 150 m, with a maximum power consumption of 3.5 W. Operating within a temperature range of 0°C to 70°C and suitable for storage between -40°C to 85°C, this XFP transceiver offers a robust solution for a variety of networking environments.
Features:
Comprehensive Monitoring
High-Speed Data Transfer
Wavelength Range
Versatile Fiber Compatibility
Reliable Link and Distance
