QIP-SDI HDMI IPTV Encoder

Add to Wish List
Out of stock
SKU
QIP-SDI-HDMI-13
$2,268.00
The dual-program QIP-SDI HDMI, with one SDI and one HDMI input, sets a new standard for sports, motion and digital signage encoding. Dual hardware scalers accept content up to 1080p, shapes digital signage for edge-to-edge presentation, and compensates for non-broadcast and PAL refresh rates. Encoding as MPEG2 or H.264, the QMOD-SDI HDMI can output the content as two SPST Multicast or Unicast IPTV streams. Options include dual-language SAP audio, easy front-panel setup and alternate audio and NTSC video inputs. Web setup, monitoring, and firmware updates are available via USB and Ethernet ports. Two-across mounting offers up to four programs per rack space, with the ability to mix models to handle HDMI, SDI, and NTSC video sources. Sources HD-SDI input, 3G Level A 1080p, 1080psf24-23.97 and 1080i/720p 59.94/60 Hz HD-SDI, and SD-SDI 480i widescreen/4:3 video; also accepts embedded 608/708 captioning and AES, PCM and AC-3 audio HDMI input (non-encrypted), 480p to 1080p, embedded PCM audio, pass-through AC-3 Two Composite/CC video inputs for encoding, captioning, or EAS use  Two analog Stereo and two SPDIF coax audio inputs Encoding Creates up to two high-definition SPST Unicast or IPTV streams, encoded as H.264 or MPEG2 Converts stereo and PCM to stereo AAC or MP12, passes through or AC-3 and AAC Can create SAP dual-language audio for each program Accepts 608/708 embedded captioning, decodes Line 21 captioning from composite video inputs  Dual hardware scalers accept up to1080p 3G video, including 60/30 Hz, and PAL formats, and can deliver programs at a scled or native resolution Dual-program operation is standard Operation Sets up with front-panel buttons and easy to use menus, including inputs, encoding, channel, and RF options. Onboard Web page for setup and monitoring, also accessible from front-panel USB port - an Ethernet connection is not required Updates firmware via USB and Ethernet Fan cooled, with adjustable speed Saves power and rack space using efficient design  Includes compact switching power supply  Mounts in included RKU 19” rack mount kit Meets RoHS safety and California energy standards Product Documents & Videos Spec Sheet Click to Download Product Manual Click to Download See More
The dual-program QIP-SDI HDMI, with one SDI and one HDMI input, sets a new standard for sports, motion and digital signage encoding. Dual hardware scalers accept content up to 1080p, shapes digital signage for edge-to-edge presentation, and compensates for non-broadcast and PAL refresh rates. Encoding as MPEG2 or H.264, the QMOD-SDI HDMI can output the content as two SPST Multicast or Unicast IPTV streams. Options include dual-language SAP audio, easy front-panel setup and alternate audio and NTSC video inputs. Web setup, monitoring, and firmware updates are available via USB and Ethernet ports. Two-across mounting offers up to four programs per rack space, with the ability to mix models to handle HDMI, SDI, and NTSC video sources. Sources HD-SDI input, 3G Level A 1080p, 1080psf24-23.97 and 1080i/720p 59.94/60 Hz HD-SDI, and SD-SDI 480i widescreen/4:3 video; also accepts embedded 608/708 captioning and AES, PCM and AC-3 audio HDMI input (non-encrypted), 480p to 1080p, embedded PCM audio, pass-through AC-3 Two Composite/CC video inputs for encoding, captioning, or EAS use  Two analog Stereo and two SPDIF coax audio inputs Encoding Creates up to two high-definition SPST Unicast or IPTV streams, encoded as H.264 or MPEG2 Converts stereo and PCM to stereo AAC or MP12, passes through or AC-3 and AAC Can create SAP dual-language audio for each program Accepts 608/708 embedded captioning, decodes Line 21 captioning from composite video inputs  Dual hardware scalers accept up to1080p 3G video, including 60/30 Hz, and PAL formats, and can deliver programs at a scled or native resolution Dual-program operation is standard Operation Sets up with front-panel buttons and easy to use menus, including inputs, encoding, channel, and RF options. Onboard Web page for setup and monitoring, also accessible from front-panel USB port - an Ethernet connection is not required Updates firmware via USB and Ethernet Fan cooled, with adjustable speed Saves power and rack space using efficient design  Includes compact switching power supply  Mounts in included RKU 19” rack mount kit Meets RoHS safety and California energy standards Product Documents & Videos Spec Sheet Click to Download Product Manual Click to Download
